Material and hardware direction
The Junior Series offers a shorter 1,200 mm door within the dimensions supplied.
Kids Toilet Cubicles
Nylon Junior Series
Toilet Cubicles
A practical Junior Series for child-focused spaces.
Our Nylon Junior Series Toilet Cubicles are specially designed to create safe, practical, and child-friendly restroom spaces. Ideal for schools, preschools, daycare centers, and educational institutions, these cubicles are designed with children’s requirements in mind, offering suitable dimensions, easy maintenance, and a comfortable environment. The Nylon Junior Series provides a practical and economical solution for creating functional and welcoming restrooms for young users.
Designed Around Your Project
For preschools, daycare centres, schools and educational institutions, the Nylon Junior Series gives project teams a clearly defined product option to evaluate. Start here for a child-oriented layout where practical nylon hardware is preferred. Its supplied schedule helps architects, contractors and facility teams compare components and confirm the correct series for their intended restroom layout.
Preschools
Daycare Centres
Schools
Educational Institutions
Key Features
Design detail
Nylon operational fittings provide an accessible everyday product specification.
Project planning advantage
Black powder-coated aluminium profiles complement busy institutional interiors.
Hardware & Profile Specification
The following list reflects the component names and quantities in VISTARAA’s supplied series sheet. Items without quantities are marked as not specified; do not treat this as a complete bill of materials.
| Supplied Component | Quantity |
|---|---|
| Nylon Polyamide - 06 Grade Thumbturn Indicator Lock | 1 no |
| Nylon Polyamide - 06 Grade Gravity Hinges | 3 nos |
| Nylon Polyamide - 06 Grade Doorknob | 1 no |
| Nylon Polyamide - 06 Grade Coat Hook | 1 no |
| Nylon Polyamide - 06 Adjustable Legs | 2 nos |
| Aluminium Black Powder Coated U Profile | Not specified |
| Aluminium Black Powder Coated H Profile | Not specified |
| Aluminium Black Powder Coated F Profile | Not specified |
| Aluminium Black Powder Coated Top rail | Not specified |
Standard Dimensions
Standard measurements shared for this particular product; validate all final dimensions and detailing for the approved project.
| Parameter | Supplied Dimension |
|---|---|
| Width | 900 mm |
| Depth | 1200 to 1350 mm |
| Height | 2000 mm |
| Door Width | 600 mm |
| Door Height | 1200 mm |
Dimensional Reference
Indicative Nylon Junior Series cubicle configuration showing the supplied standard dimensions.
Width
900 mm
Depth
1200–1350 mm
Overall Height
2000 mm
Door Width
600 mm
Door Height
1200 mm
Illustrative dimensional reference only. Not to scale or intended for fabrication. Confirm Junior Series proportions, hardware arrangements and final dimensions against approved project drawings.
Where This Product Fits
The Junior Series is intended for preschools, daycare centres, schools and educational institutions. Confirm the intended age group, adult supervision requirements, accessible facilities and the dimensions of the surrounding sanitary fixtures as part of the wider restroom plan.
Preschools
Daycare Centres
Schools
Educational
Institutions
Frequently Asked Questions
Is this suitable for every age group?
The source provides a Junior range with 1,200 mm door heights, but suitability depends on age group, supervision, accessibility and the site’s approved design requirements.
Are the listed sizes the final installed dimensions?
They are the standard measurements shown in the supplied VISTARAA sheet. Confirm final sizes, site conditions, door clearances and relevant project requirements with the VISTARAA team before approval.
Let's Specify the
Right Solution
Share your project drawings, location, approximate number of units and preferred finish or detailing. Mention Nylon Junior Series Toilet Cubicles so the enquiry can be directed to the appropriate product discussion.
